Low total cost of ownership (TCO)
Additional computing access is as simple as adding more I/O devices. The total cost of ownership is then drastically reduced.
Slim and quiet design
m321 is feather light weighing only 160g (approximate). The slim design allows it to be mounted to the back of a monitor with a VESA mount. Together with its fanless design, m321 helps create a simple and noiseless workplace environment.
LAN-based connection
m321 connects to the host server with an Ethernet cable. This connection type exceeds the length limit of a USB connection and provides more flexibility in the layout of a MultiPoint Server system.
Simple setup
Just attach a keyboard, mouse, and monitor to your m321, connect it to the host server, and then perform the initial setup. A station is ready for use right away.
Easy management and maintenance
Since all computing tasks are performed on a server, all hardware and software issues are gone on the client side. All user management, software installations, system management, and upgrades are done on a single server.
| Processor | SOC SMSC UFX6000 |
|---|---|
| Maximum resolution | 1920 x 1080 |
| Video | VGA-type video output (D-sub 15) |
| I/O ports | 1 x DVI-I 2 x USB A type (for keyboard and mouse) 2 x USB A type (for other USB devices) 1 x Gigabit Ethernet (to the host server) 1 x headphone 1 x microphone 1 x DC IN 1 x Kensington lock slot |
| Host connection | 10/100/1000Mb Gigabit Ethernet |
| Dimensions | (W) 120 x (D ) 80 x (H) 26 mm |
| Weight | 160g (approximate, AC adaptor excluded) |
| Cooling | Fanless |
| Operating noise | No noise |
| Operating temperature | 0℃ ~ 35℃ |
| Non-operating temperature | -30℃ ~ 60℃ |
| Operating humidity (Rh) | 10% ~ 90% (non-condensing) |
| Non-operating humidity (Rh) | 5% ~ 95% |
| Operating / Output voltage | 100 ~ 240 VAC / +5V DC |
| Rated line frequency | 50 ~ 60 Hz |
| Rated output current (max) | 2A |
| Server OS Support | Windows® MultiPoint™ Server 2012 Userful Multiplatform™ |
| Regulatory | CB, NRTL, FCC, CE |
| Option | VESA Mount Kit (W) 114 x (D) 60 x (H) 6 mm |
