Reliable High Performance
In addition to milling on X, Y and Z axes, the DWX-4W rotates pin-type blocks 360 degrees on a fourth axis (A axis) to support undercuts. The ball screw-driven 4-axis control allows for smooth, high-precision machining. The DWX-4W's high-performance 60,000-RPM Jaeger spindle is known for its reliability and supports precision milling of glass ceramics and composite resin. With its multi-pin clamp, the DWX-4W is a wet dental milling machine that can mill up to three different pin-type materials continuously in one operation. As a result, prosthetics for up to three different patients can be produced in a single production run, saving time, labor and costs.
Distinguishing Features
The DWX-4W is designed so that even novice users can quickly and easily begin creating precision prosthetics. The workflow is simple: after installing the material and mialling tools into the machine, lab technicians use the Virtual Machine Panel (VPanel) to configure settings from their computer and operate the automatic machine calibration to ensure machine accuracy, then automatically send CAM data to the DWX-4W to begin production. Users receive e-mail notifications detailing any errors, or when milling is completed, while color-coded LED status lights inform the user of current progress.
Using separate dry and wet DWX devices gives you the confidence to take on the maximum amount of glass ceramic and zirconia restorations without the need for time-consuming, back-and-forth set-up and cleaning of a single machine.
DWX-4W Wet Dental Mill | |
---|---|
Cuttable material | Glass ceramics, Composite resin |
Loadable workpiece shape | Width: Maximum 40 mm (1.57 in) Depth: Maximum 20 mm (0.79 in) Height: Maximum 20 mm (0.79 in) |
Operating speed | 6 to 1,800 mm/min. (0.24 to 70.9 in./min.) |
Spindle motor | Jaeger high frequency spindle |
Spindle speed | 15,000 to 60,000 rpm |
Rotary axis travel angle | A axis: ±360° |
Number of burs housed | 4 |
Attachable bur | Shank diameter: 3 mm Dedicated milling bur for wet grinding |
Compatible compressed air | 0.02 to 0.2 MPa |
Interface | USB |
Control command set | RML-1, NC code |
Power requirements | AC 100 to 240 V ± 10%, 50/60 Hz , 1.9 A (overvoltage category II, IEC 60664-1) |
Power consumption | Approx. 200 W |
External dimensions | Width x Depth x Height: 480 x 538 x 599 mm (18.9 x 21.2 x 23.6 in.) |
Weight | 67 kg (147.7 lbs.) |
